| Uimhir Pháirt | AM-1024600L2HMQW-T01H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM-1024600L2HMQW-T01H |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 117PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 222.72(H)×125.28(V) mm |
| imlíne dim. | 235(H)×145.8(V) ×9.8(D) mm |
| limistéar bezel | 225.92(H)×128.48(V) mm |
| cóireáil | - |
| luminance | 800 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 4/12 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/70/50 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 47% NTSC |
| foinse solais | WLED [6S6P] , 50K hours , With LED Driver |
| meáchan | TBD |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | 4-wire Resistive Touch |
| cineál comhéadan | LVDS (1 ch, 6-bit) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
