| Uimhir Pháirt | AM-1024600K8TMQW-T09H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | 5S3P |
| Comhéadan | |
| monaróir | AMPIRE |
| ainm samhail | AM-1024600K8TMQW-T09H |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 169PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 153.6 × 90 (H×V) |
| imlíne (mm) | 165.5 × 104.4 × 10.77 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Glare (Haze 0%), Hard coating |
| luminance | 425 cd/m² (Typ.) |
| cóimheas codarsnachta | 700 : 1 (Typ.) (TM) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| freagra | 20/20 (Typ.)(Tr/Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 16.7M |
| cúlsolas | 5S3P WLED , 30K hours , With LED Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | PCAP |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
