| Uimhir Pháirt | AM-1024600K7TMQW-T19H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | AMPIRE |
| méid trasnánach | 7.0 inch |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 169PPI |
| limistéar gníomhach | 153.6(H)×90(V) mm |
| luminance | 425 cd/m² (Typ.) |
| treo amharc | 6 o'clock |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M |
| meáchan | TBD |
| ráta fhráma | 60Hz |
| Mionsamhail | AM-1024600K7TMQW-T19H |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 165.5(H)×104.44(V) ×10.81(D) mm |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| am freagartha | 20/20 (Typ.)(Tr/Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED [5S3P] , 30K hours , With LED Driver |
| deartha le haghaidh | Industrial |
| painéal tadhaill | PCAP |
