| Uimhir Pháirt | AM-1024600K7TMQW-T04H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | 8S3P |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 7.0" |
| taifeach | 1024(RGB)×600, WSVGA, 169PPI |
| limistéar taispeána | 153.6(W)×90(H) mm |
| méid imlíne | 165.5(W)×104.44(H) ×10.81(D) mm |
| gile | 850 cd/m² (Typ.) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| radharc is fearr ar | 6 o'clock |
| dathanna a thaispeáint | 262K |
| minicíocht | 60Hz |
| meáchan | TBD |
| múnla painéil | AM-1024600K7TMQW-T04H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | - |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 20/20 (Typ.)(Tr/Td) |
| cineál lampa | 8S3P WLED , 50K hours , With LED Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070VW05 V0 | AUO | 7.0 | 800×480 |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
