| Uimhir Pháirt | AM-1024600ITZQW-T00H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| méid scáileáin | 10.1 inch |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 117PPI |
| limistéar gníomhach(mm) | 222.72 × 125.28 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 465 cd/m² (Typ.) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 262K/16.7M 70% NTSC |
| mais | - |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| soláthar voltais | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ainm samhail | AM-1024600ITZQW-T00H |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 255 × 165.8 (H×V×D) |
| cóireáil | Antiglare, Hard coating |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| freagra | 12/28 (Typ.)(Tr/Td) ms |
| modh oibre | IPS, Normally Black, Transmissive |
| cúlsolas | WLED , 50K hours , No Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | PCAP |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| LTN101AL01-F01 | Samsung | 10.1 | 1280×800 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
