| Uimhir Pháirt | AM-1024600DTZQW-TA0H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 7.0" |
| taifeach | 1024(RGB)×600, WSVGA, 170PPI |
| limistéar taispeána | 154.221(W)×85.92(H) mm |
| méid imlíne | 184(W)×128(H) ×12.6(D) mm |
| gile | 425 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 58% NTSC |
| minicíocht | 60Hz |
| meáchan | - |
| múnla painéil | AM-1024600DTZQW-TA0H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | IPS, Normally Black, Transmissive |
| am freagartha | 13/15 (Typ.)(Tr/Td) |
| cineál lampa | WLED , 30K hours , With LED Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial |
