| Uimhir Pháirt | AM-1024600DTZQW-A6H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 1024×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| ainm samhail | AM-1024600DTZQW-A6H |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 170PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 154.221 × 85.92 (H×V) |
| imlíne (mm) | 164.9 × 100 (H×V×D) |
| limistéar bezel (mm) | 158 × 89.7 (H×V) |
| cóireáil | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 13/15 (Typ.)(Tr/Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | IPS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M |
| cúlsolas | WLED , 50K hours , With LED Driver |
| mais | - |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
