| Uimhir Pháirt | WF57STIACDNN0 |
| Branda | Winstar |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 320×240 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | Grayscale |
| Cúlsolas | WLED |
| Comhéadan | 8/16-bit |
| branda painéil | Winstar |
| méid an phainéil | 5.7" |
| taifeach | 320×240, QVGA, 70PPI |
| limistéar taispeána | 115.2(W)×86.4(H) mm |
| méid imlíne | 160(W)×109(H) ×7.5(D) mm |
| gile | 1000 cd/m² (Typ.) |
| uillinn féachana | - |
| radharc is fearr ar | 12 o'clock |
| dathanna a thaispeáint | Grayscale |
| minicíocht | - |
| meáchan painéal | - |
| comhéadan comhartha | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | WF57STIACDNN0 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | Rectangle |
| oscailt bezel | 122.0(W)×92.0(H) mm |
| dromchla | Glare (Haze 0%) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | - |
| cineál lampa | WLED , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G057VN01 V0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G04 | Kyocera | 5.7 | 320×240 |
| KG057QV1DB-G00 | Kyocera | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| LTA057A344F | TOSHIBA | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
