| Uimhir Pháirt | WF39BTLASDNG0 |
| Branda | Winstar |
| Méid | 3.9 |
| Iarratas | Industrial Stretched |
| Rún | 480×128 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda painéil | Winstar |
| múnla painéil | WF39BTLASDNG0 |
| méid an phainéil | 3.9" (1/2 cut of 4.3") |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 480×128(RGB), 128PPI |
| formáid picteilín | RGB Horizontal Stripe |
| limistéar taispeána | 95.04(W)×25.34(H) mm |
| oscailt bezel | 97.04(W)×27.34(H) mm |
| méid imlíne | 105.5(W)×37(H) ×5.63(D) mm |
| dromchla | Glare (Haze 0%) |
| gile | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| uillinn féachana | - |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | 6 o'clock |
| am freagartha | - |
| dathanna a thaispeáint | 16.7M |
| cineál lampa | WLED , Without Driver |
| minicíocht | - |
| scáileán tadhaill | PCAP |
| meáchan painéal | - |
| iarratas | Industrial Stretched Bar LCD |
| comhéadan comhartha | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
