| Uimhir Pháirt | WEO002002AS |
| Branda | Winstar |
| Méid | 2.9 |
| Iarratas | Instruments & Me |
| Rún | 20×26 |
| Comhdhéanamh | PM-OLED, OLED |
| Gile | |
| CR | 2000:1 |
| Dathanna | Mono(Blue) |
| Cúlsolas | self |
| Comhéadan | 8-bit |
| branda painéil | Winstar |
| múnla painéil | WEO002002AS |
| méid an phainéil | 2.9" |
| cineál painéil | PM-OLED, OLED |
| formáid taispeána | 20 characters × 2 lines, 6PPI |
| cruth cló | 5×8 dots |
| méid carachtar | 3.22×5.57(W×H) mm |
| páirc carachtar | 3.7×5.95(W×H) mm |
| limistéar taispeána | 73.52(W)×11.52(H) mm |
| oscailt bezel | 75.32(W)×13.52(H) mm |
| méid imlíne | 84.5(W)×19.2(H) ×2.15(D) mm |
| dromchla | - |
| gile | - |
| cóimheas codarsnachta | 2000:1 (Typ.) (TM) |
| uillinn féachana | 88/88/88/88 |
| mód taispeána | - |
| radharc is fearr ar | Symmetry |
| am freagartha | 0.01 (Typ.) |
| dathanna a thaispeáint | Mono(Blue) |
| cineál lampa | self |
| minicíocht | - |
| scáileán tadhaill | Without |
| Tiománaí ic | COG Built-in SSD1311M1Z |
| meáchan painéal | - |
| iarratas | Instruments & Meters |
| comhéadan comhartha | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 32 pins FPC |
| voltas ionchuir | 3.3/5.0V (Typ.)(VDD) |
