| Uimhir Pháirt | WEH002002BS |
| Branda | Winstar |
| Méid | 5.7 |
| Iarratas | Instruments & Meters |
| Rún | 20×23 |
| Comhdhéanamh | PM-OLED , OLED |
| Gile | |
| CR | |
| Dathanna | Mono(Blue) |
| Cúlsolas | self |
| Comhéadan | CPU/SPI |
| branda painéil | Winstar |
| méid an phainéil | 5.7" |
| formáid taispeána | 20 characters × 2 lines, 3PPI |
| méid carachtar | 6×9.66(W×H) mm |
| limistéar taispeána | 145.08(W)×20.64(H) mm |
| méid imlíne | 180(W)×40(H) ×9.3(D) mm |
| uillinn féachana | - |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | Mono(Blue) |
| minicíocht | - |
| Tiománaí ic | COB Built-in WS0010 |
| meáchan painéal | - |
| comhéadan comhartha | CPU/SPI , 16 pins Pad |
| voltas ionchuir | 5.0V (Typ.) |
| múnla painéil | WEH002002BS |
| cineál painéil | PM-OLED , OLED |
| cruth cló | 5×8 dots |
| páirc carachtar | 7.32×10.98(W×H) mm |
| oscailt bezel | 149.0(W)×23.0(H) mm |
| dromchla | - |
| mód taispeána | - |
| am freagartha | - |
| cineál lampa | self |
| scáileán tadhaill | Without |
| iarratas | Instruments & Meters |
