| Uimhir Pháirt | VLT170-SBL-SXGA-135 |
| Branda | Vitrolight |
| Méid | 14.3 |
| Iarratas | Stretched Bar LCD Di |
| Rún | 1280×512 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | Vitrolight |
| múnla painéil | VLT170-SBL-SXGA-135 |
| méid an phainéil | 14.3" (1/2 cut of 17.0") |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1280(RGB)×512, 96PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 337.92(W)×135(H) mm |
| oscailt bezel | 341.92(W)×140.85(H) mm |
| méid imlíne | 358.5(W)×162(H) ×10.3(D) mm |
| dromchla | - |
| gile | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | 85/85/80/80 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | - |
| am freagartha | 3.8 (Typ.)(G to G) |
| dathanna a thaispeáint | 16.7M 72% NTSC |
| cineál lampa | WLED |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | - |
| iarratas | Stretched Bar LCD Digital Signage |
| comhéadan comhartha | LVDS (2 ch, 8-bit) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; - |
