Chimei Innolux V500HJ1-PE8 Rev.C7 bileog sonraí, sonraíocht, stoic, feidhmchlár www.looklcd-ie.com
LookLCD LookLCD


V500HJ1-PE8 Rev.C7

V500HJ1-PE8 Rev.C7
V500HJ1-PE8 Rev.C7
V500HJ1-PE8 Rev.C7 thumb V500HJ1-PE8 Rev.C7 thumb
Branda
Chimei Innolux
Méid
50
Iarratas
Transparent Display
Rún
1920×1080
Comhdhéanamh
a-Si TFT-LCD, CELL
Gile
CR
5000:1
Dathanna
16.7M
Cúlsolas
No
Comhéadan
LVDS
In Stock
14118
Sonraíochtaí

Uimhir Pháirt V500HJ1-PE8 Rev.C7
BrandaChimei Innolux
Méid50
IarratasTransparent Display
Rún1920×1080
Comhdhéanamha-Si TFT-LCD, CELL
Gile
CR5000:1
Dathanna16.7M
CúlsolasNo
ComhéadanLVDS
brandaChimei Innolux
MionsamhailV500HJ1-PE8 Rev.C7
méid trasnánach50 inch
cineála-Si TFT-LCD, CELL
formáid picteilín1920(RGB)×1080  [FHD]  44PPI
cumraíochtRGB Vertical Stripe
limistéar gníomhach1095.84(H)×616.41(V) mm
imlíne dim.1116.38(H)×631.61(V) ×1.31(D) mm
limistéar bezel-
cóireáilAntiglare (Haze 1%), Hard coating (3H)
luminance0 cd/m²
cóimheas codarsnachta5000:1 (Typ.) (TM)
treo amharcSymmetry
am freagartha8.5 (Typ.)(G to G)
uillinn féachana88/88/88/88 (Typ.)(CR≥20)
modh oibriúcháinSuper MVA, Normally Black, Transmissive
tiús pláta-
tarchur5.6% (Typ.)(with Polarizer)
dath tacaíochta16.7M   70% NTSC
foinse solaisNo B/L
meáchan1.99±0.199Kgs
deartha le haghaidhTransparent Display
ráta fhráma60Hz
painéal tadhaillWithout
sonraí d-icCOF Built-in 6 source + 4 gate chips
cineál comhéadanLVDS (2 ch, 8-bit) Connector
soláthar leictreachas12.0V (Typ.)
timpeallachtOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Múnla Teaghlaigh
T500HVD01.0 AUO 50 1920×1080
T500HVN04.5 CELL AUO 50 1920×1080
T500HVN05.0 CELL AUO 50 1920×1080
V500DJ2-QS5 Innolux 50 3840×2160
V500HJ1-L01 Innolux 50 1920×1080
V500HJ1-ME1 Innolux 50 1920×1080
V500HJ1-PE6 Innolux 50 1920×1080
V500HJ1-PE8 Innolux 50 1920×1080
V500HK1-LE6 Innolux 50 1920×1080
V500HK2-PS1 Innolux 50 1920×1080
