| Uimhir Pháirt | V236BJ1-P01 Rev.CB |
| Branda | Innolux |
| Méid | 23.6 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | CELL , a-Si TFT-LC |
| Gile | |
| CR | 3000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | Innolux |
| ainm samhail | V236BJ1-P01 Rev.CB |
| méid scáileáin | 23.6 inch |
| cineál scáileáin | CELL , a-Si TFT-LCD |
| uimhir picteilín | 1366(RGB)×768 (WXGA) 66PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 521.471 × 293.184 (H×V) |
| imlíne (mm) | 535.06 × 307.34 × 1.32 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Antiglare (Haze 1%) |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 3000 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 8.5 (Typ.)(G to G) ms |
| radharc maith ag | Symmetry |
| modh oibre | MVA, Normally Black, Transmissive |
| tiús gloine | 0.50+0.50 mm |
| transmissivity | 5.6% (Typ.)(with Polarizer) |
| doimhneacht dath | 16.7M 69% NTSC |
| cúlsolas | No B/L |
| mais | 510g (Typ.) |
| a úsáidtear le haghaidh | TV Sets |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Ic liosta tiománaí | Built-in COF 2 source chips |
| cineál comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LQ235D1LW03 | SHARP | 23.6 | 1920×1080 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
| P236MWF1 R2 | IVO | 23.6 | 1920×1080 |
| V236BJ1-LE2 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P02 | Innolux | 23.6 | 1366×768 |
| V236BJ1-P03 | Innolux | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
