| Uimhir Pháirt | V236BJ1-LE2 Rev.CA |
| Branda | Innolux |
| Méid | 23.6 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | Innolux |
| Mionsamhail | V236BJ1-LE2 Rev.CA |
| méid trasnánach | 23.6 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1366(RGB)×768 [WXGA] 66PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 521.471(H)×293.184(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 8.5 (Typ.)(G to G) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| modh oibriúcháin | AAS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 72% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | TV Sets |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar leictreachas | 12.0V (Typ.) |
| timpeallacht | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
