| Uimhir Pháirt | UG-2828GDEDF15 |
| Branda | Univision |
| Méid | 1.5 |
| Iarratas | Mobile Phone Handhel |
| Rún | 128×128 |
| Comhdhéanamh | PM-OLED, OLED |
| Gile | |
| CR | 2000:1 |
| Dathanna | 262K |
| Cúlsolas | self |
| Comhéadan | 8-bit |
| branda | Univision |
| Mionsamhail | UG-2828GDEDF15 |
| méid trasnánach | 1.5 inch |
| cineál | PM-OLED, OLED |
| formáid picteilín | 128(RGB)×128 121PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 26.855(H)×26.864(V) mm |
| imlíne dim. | 33.8(H)×34(V) ×1.7(D) mm |
| limistéar bezel | 28.855(H)×28.864(V) mm |
| cóireáil | - |
| luminance | 90 cd/m² (Typ.) |
| cóimheas codarsnachta | 2000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | - |
| uillinn féachana | 80/80/80/80 (Min.) |
| modh oibriúcháin | - |
| dath tacaíochta | 262K |
| foinse solais | self , 20K hours |
| meáchan | 3.80g (Typ.) |
| deartha le haghaidh | Mobile Phone Handheld & PDA |
| ráta fhráma | - |
| painéal tadhaill | Without |
| sonraí d-ic | COF Built-in SSD1351 |
| cineál comhéadan | 8-bit 6800/8080 parallel, 3/4-wire SPI , 30 pins FPC |
| soláthar leictreachas | 2.8/2.5/1.8/13V (Typ.)(VCI/VDD/VDDIO/VCC) |
| timpeallacht | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C |
