| Uimhir Pháirt | TX26D207VM0AAA |
| Branda | KOE |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1500:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | KOE |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1280(RGB)×800 [WXGA] 149PPI |
| limistéar gníomhach | 217.344(H)×135.84(V) mm |
| limistéar bezel | 220.344(H)×138.838(V) mm |
| luminance | 1000 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 65% NTSC |
| meáchan | 340g (Typ.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| Mionsamhail | TX26D207VM0AAA |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 231(H)×153.5(V) ×11.07(D) mm |
| cóireáil | - |
| cóimheas codarsnachta | 1500:1 (Typ.) (TM) |
| am freagartha | 25 (Max.)(Tr+Tf) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| foinse solais | WLED , 70K hours , With LED Driver |
| deartha le haghaidh | Industrial Outdoor High Brightness Automotive Display |
| painéal tadhaill | Without |
