| Uimhir Pháirt | TX20D208VM0BAA |
| Branda | HITACHI |
| Méid | 8.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | HITACHI |
| múnla painéil | TX20D208VM0BAA |
| méid an phainéil | 8.0" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 800(RGB)×480, WVGA, 116PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 174(W)×104.4(H) mm |
| oscailt bezel | 177.4(W)×107.8(H) mm |
| méid imlíne | 190.8(W)×120.5(H) ×16.2(D) mm |
| dromchla | - |
| gile | 1200 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | IPS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Max.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 70% NTSC |
| cineál lampa | WLED , 100K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 275g (Typ.) |
| iarratas | Industrial Outdoor High Brightness Automotive Display |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
