| Uimhir Pháirt | TX18D211VM0BAA |
| Branda | KOE |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | LTPS TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | KOE |
| múnla painéil | TX18D211VM0BAA |
| méid an phainéil | 7.0" |
| cineál painéil | LTPS TFT-LCD, LCM |
| taifeach | 800(RGB)×480, WVGA, 133PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 152.4(W)×91.44(H) mm |
| oscailt bezel | 156.2(W)×94.5(H) mm |
| méid imlíne | 167.7(W)×109.5(H) ×20.3(D) mm |
| dromchla | - |
| gile | 1200 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | IPS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 262K 73% NTSC |
| cineál lampa | WLED , 50K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 219g (Typ.) |
| iarratas | Industrial Outdoor High Brightness Automotive Display |
| comhéadan comhartha | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
