| Uimhir Pháirt | TX18D210VM0BAA |
| Branda | KOE |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | LCM , LTPS TFT-LCD |
| Gile | |
| CR | 1200:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| monaróir | KOE |
| méid scáileáin | 7.0 inch |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| limistéar bezel (mm) | 156.2 × 94.5 (H×V) |
| luminance | 800 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 262K 72% NTSC |
| mais | 214g (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| ainm samhail | TX18D210VM0BAA |
| cineál scáileáin | LCM , LTPS TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| cóireáil | - |
| cóimheas codarsnachta | 1200 : 1 (Typ.) (TM) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| modh oibre | IPS, Normally Black, Transmissive |
| cúlsolas | WLED , 50K hours , With LED Driver |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness Automotive Display |
| scáileán tadhaill | Without |
