| Uimhir Pháirt | TX09D30VM1CCA |
| Branda | KOE |
| Méid | 3.5 |
| Iarratas | HHP |
| Rún | 240×320 |
| Comhdhéanamh | LCM |
| Gile | 250 |
| CR | 300:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | HITACHI |
| múnla painéil | TX09D30VM1CCA |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 3.5 inch |
| taifeach | 240(RGB)×320 , QVGA |
| mód taispeána | TN, Normally White, TMR |
| limistéar gníomhach | 53.64×71.52 mm |
| imlíne | 64×86×7.9 mm |
| dromchla | Antiglare |
| gile | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 300 : 1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193150% |
| am freagartha | 15/15 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | CMOS (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | HHP |
