| Uimhir Pháirt | TV101WXM-AG0 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 800×1280 |
| Comhdhéanamh | Assembly , a-Si TF |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S6P |
| Comhéadan | MIPI |
| monaróir | BOE |
| ainm samhail | TV101WXM-AG0 |
| méid scáileáin | 10.1 inch |
| cineál scáileáin | Assembly , a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×1280 (WXGA) 150PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 135.322 × 216.463 (H×V) |
| imlíne (mm) | 164 × 245.2 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Anti Fingerprint, Hard coating (7H) |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | - |
| doimhneacht dath | 16.7M 57% NTSC |
| cúlsolas | 6S6P WLED , 15K hours , No Driver |
| mais | 300g (Max.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | PCAP |
| cineál comhartha | MIPI (4 data lanes) , 51 pins Connector |
| soláthar voltais | 3.3/5.5/-5.5V (Typ.)(VDDIO/AVDD/AVEE) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| LTL101DL03-T01 | Samsung | 10.1 | 2560×1600 |
| M101NWWB R6 | IVO | 10.1 | 1280×800 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
| TV101WXM-NP1 | BOE | 10.1 | 1280×800 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
