| Uimhir Pháirt | TV101WUM-NW1 |
| Branda | No Brand |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 8S4P |
| Comhéadan | MIPI |
| branda painéil | No Brand |
| méid an phainéil | 10.1" |
| taifeach | 1200(RGB)×1920, WUXGA, 225PPI |
| limistéar taispeána | 135.36(W)×216.576(H) mm |
| méid imlíne | 142.76(W)×228.18(H) ×4.2(D) mm |
| gile | 450 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 100% sRGB |
| minicíocht | 60Hz |
| meáchan painéal | TBD |
| comhéadan comhartha | MIPI (4 data lanes) , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| múnla painéil | TV101WUM-NW1 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Clear, Hard coating |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | HADS, Normally Black, Transmissive |
| am freagartha | 30 (Typ.)(Tr+Td) |
| cineál lampa | 8S4P WLED , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Pad & Tablet |
