| Uimhir Pháirt | TV101WUM-NL1 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 8S4P |
| Comhéadan | MIPI |
| monaróir | BOE |
| ainm samhail | TV101WUM-NL1 |
| méid scáileáin | 10.1 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1200(RGB)×1920 (WUXGA) 225PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 135.36 × 216.576 (H×V) |
| imlíne (mm) | 142.96 × 227.926 × 3.8 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Anti Fingerprint + Clear, Hard coating |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | HADS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 98% sRGB |
| cúlsolas | 8S4P WLED , 15K hours , No Driver |
| mais | 105g (Typ.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | MIPI (4 data lanes) , Connector 45 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
