| Uimhir Pháirt | TV101WUB-NV0 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | a-Si TFT-LCD, CELL |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | MIPI |
| branda | BOE |
| Mionsamhail | TV101WUB-NV0 |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, CELL |
| formáid picteilín | 1200(RGB)×1920 [WUXGA] 225PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 135.36(H)×216.576(V) mm |
| imlíne dim. | 140.26(H)×225.346(V) ×0.8(D) mm |
| luminance | 0 cd/m² |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | ADS, Normally Black, Transmissive |
| tiús pláta | 0.25+0.25 mm |
| tarchur | 5.1% (Typ.)(with Polarizer) |
| dath tacaíochta | 16.7M 71% NTSC |
| foinse solais | No B/L |
| meáchan | - |
| deartha le haghaidh | Pad & Tablet |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| sonraí d-ic | COG Built-in 2 source chips |
| cineál comhéadan | MIPI (4 data lanes) , 44 pins Connector |
| soláthar leictreachas | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
