| Uimhir Pháirt | TV097FMM-LB0-1SP0 |
| Branda | BOE |
| Méid | 9.7 |
| Iarratas | Pad & Tablet |
| Rún | 1280×1752 |
| Comhdhéanamh | a-Si TFT-LCD , Assem |
| Gile | |
| CR | 1200:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | MIPI |
| branda | BOE |
| méid trasnánach | 9.7 inch |
| formáid picteilín | 1280(RGB)×1752 223PPI |
| limistéar gníomhach | 145.344(H)×198.94(V) mm |
| limistéar bezel | - |
| luminance | 320 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 70% NTSC |
| meáchan | 115g (Max.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | MIPI (4 data lanes) , 45 pins Connector |
| soláthar leictreachas | 1.8/5.7/-5.7V (Typ.)(VDD/AVDD/AVEE) |
| timpeallacht | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Mionsamhail | TV097FMM-LB0-1SP0 |
| cineál | a-Si TFT-LCD , Assembly |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 150.344(H)×208.29(V) mm |
| cóireáil | Clear, Hard coating |
| cóimheas codarsnachta | 1200:1 (Typ.) (TM) |
| am freagartha | 35 (Max.)(G to G) |
| modh oibriúcháin | - |
| foinse solais | WLED [9S4P] , 15K hours , W/O Driver |
| deartha le haghaidh | Pad & Tablet |
| painéal tadhaill | In-Cell Touch |
