| Uimhir Pháirt | TV080WXM-NS1 |
| Branda | BOE |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 800×1280 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1100:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | MIPI |
| branda | BOE |
| méid trasnánach | 8.0 inch |
| formáid picteilín | 800(RGB)×1280 [WXGA] 188PPI |
| limistéar gníomhach | 107.64(H)×172.224(V) mm |
| luminance | 530 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 87% NTSC |
| meáchan | - |
| ráta fhráma | 60Hz |
| cineál comhéadan | MIPI (4 data lanes) , 34 pins Connector |
| soláthar leictreachas | 1.8/5.4/-5.4V (Typ.)(VDD1/PVDD/NVDD) |
| timpeallacht | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Mionsamhail | TV080WXM-NS1 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 114.65(H)×183.853(V) ×3.56(D) mm |
| cóimheas codarsnachta | 1100:1 (Typ.) (TM) |
| am freagartha | 30 (Typ.)(Tr+Td) |
| modh oibriúcháin | ADS, Normally Black, Transmissive |
| foinse solais | WLED [3 strings] , W/O Driver |
| deartha le haghaidh | Pad & Tablet |
| painéal tadhaill | Without |
