| Uimhir Pháirt | TV080WUM-TL1 |
| Branda | BOE |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | a-Si TFT-LCD, Assemb |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | BOE |
| Mionsamhail | TV080WUM-TL1 |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, Assembly |
| formáid picteilín | 1200(RGB)×1920 [WUXGA] 283PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 107.64(H)×172.224(V) mm |
| imlíne dim. | 117.7(H)×193.84(V) ×5.5(D) mm |
| limistéar bezel | - |
| cóireáil | Hard coating |
| luminance | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| modh oibriúcháin | HADS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 58% NTSC |
| foinse solais | WLED [6S4P] , W/O Driver |
| meáchan | 155g (Max.) |
| deartha le haghaidh | Pad & Tablet |
| ráta fhráma | 60Hz |
| painéal tadhaill | On-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
