| Uimhir Pháirt | TV070WSM-TL1 |
| Branda | BOE |
| Méid | 7.0 |
| Iarratas | Pad & Tablet |
| Rún | 600×1024 |
| Comhdhéanamh | Assembly , a-Si TF |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S3P |
| Comhéadan | MIPI |
| monaróir | BOE |
| ainm samhail | TV070WSM-TL1 |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | Assembly , a-Si TFT-LCD |
| uimhir picteilín | 600(RGB)×1024 (WSVGA) 170PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 89.28 × 152.37 (H×V) |
| imlíne (mm) | 97 × 188.26 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Hard coating |
| luminance | 300 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 30 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | - |
| doimhneacht dath | 16.7M 50% NTSC |
| cúlsolas | 6S3P WLED , No Driver |
| mais | 125g (Max.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | On-Cell Touch |
| cineál comhartha | MIPI (4 data lanes) , 39 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 60 °C |
