| Uimhir Pháirt | TV070HDM-TL0-39P0 |
| Branda | BOE |
| Méid | 7.0 |
| Iarratas | Pad & Tablet |
| Rún | 720×1280 |
| Comhdhéanamh | a-Si TFT-LCD, Assemb |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S3P |
| Comhéadan | MIPI |
| branda painéil | BOE |
| múnla painéil | TV070HDM-TL0-39P0 |
| méid an phainéil | 7.0" |
| cineál painéil | a-Si TFT-LCD, Assembly |
| taifeach | 720(RGB)×1280, WXGA, 209PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 87.2654(W)×155.136(H) mm |
| oscailt bezel | - |
| méid imlíne | 93.08(W)×183.38(H) mm |
| dromchla | Hard coating |
| gile | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| mód taispeána | - |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 55% NTSC |
| cineál lampa | 6S3P WLED , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | On-Cell Touch |
| meáchan painéal | 130g (Max.) |
| iarratas | Pad & Tablet |
| comhéadan comhartha | MIPI (4 data lanes) , 39 pins Connector |
| voltas ionchuir | 1.8/5.0/-5.0V (Typ.)(VDDI/VSP/VSN) |
| timpeallacht | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
