| Uimhir Pháirt | TM123XDHP90 |
| Branda | TIANMA |
| Méid | 12.3 |
| Iarratas | Industrial Outdoor H |
| Rún | 1920×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 10S4P |
| Comhéadan | LVDS |
| branda painéil | TIANMA |
| múnla painéil | TM123XDHP90 |
| méid an phainéil | 12.3" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1920(RGB)×720, 166PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 292.32(W)×109.62(H) mm |
| oscailt bezel | - |
| méid imlíne | 311(W)×130(H) ×15.7(D) mm |
| dromchla | Antiglare (Haze 28%) |
| gile | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| uillinn féachana | - |
| mód taispeána | SFT, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 98% sRGB |
| cineál lampa | 10S4P WLED , 10K hours , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 490g (Typ.) |
| iarratas | Industrial Outdoor High Brightness Automotive Display |
| comhéadan comhartha | LVDS (2 ch, 8-bit) , 50 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
