| Uimhir Pháirt | TM116VDSP03 |
| Branda | TIANMA |
| Méid | 11.6 |
| Iarratas | Industrial Outdoor H |
| Rún | 1920×1080 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | 9S6P |
| Comhéadan | LVDS |
| monaróir | TIANMA |
| ainm samhail | TM116VDSP03 |
| méid scáileáin | 11.6 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×1080 (FHD) 190PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 256.32 × 144.18 (H×V) |
| imlíne (mm) | 273.5 × 166.5 × 11.5 (H×V×D) |
| limistéar bezel (mm) | 259.31 × 148.73 (H×V) |
| cóireáil | Hard coating |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 900 : 1 (Typ.) (TM) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | SFT, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 70% NTSC |
| cúlsolas | 9S6P WLED , 50K hours , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (2 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 3.3/10.7/20/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| uas. rátálacha | Storage Temp.: -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
