| Uimhir Pháirt | TM104TDGP10 |
| Branda | TIANMA |
| Méid | 10.4 |
| Iarratas | Industrial |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1200:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 8S4P |
| Comhéadan | LVDS |
| branda painéil | TIANMA |
| méid an phainéil | 10.4" |
| taifeach | 1024(RGB)×768, XGA, 123PPI |
| limistéar taispeána | 210.432(W)×157.824(H) mm |
| méid imlíne | 230(W)×175.8(H) ×9.06(D) mm |
| gile | 450 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 262K/16.7M 50% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 430g (Typ.) |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | TM104TDGP10 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 213.43(W)×160.82(H) mm |
| dromchla | Antiglare |
| cóimheas codarsnachta | 1200:1 (Typ.) (TM) |
| mód taispeána | SFT, Normally Black, Transmissive |
| am freagartha | 35 (Typ.)(Tr+Td) |
| cineál lampa | 8S4P WLED , With LED Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
