| Uimhir Pháirt | TM103XDHP95 |
| Branda | TIANMA |
| Méid | 10.3 |
| Iarratas | Outdoor High Brightn |
| Rún | 1920×720 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 11S3P |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM103XDHP95 |
| méid scáileáin | 10.3 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1920(RGB)×720 200PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 243.648 × 91.368 (H×V) |
| imlíne (mm) | 261 × 110.5 × 14.65 (H×V×D) |
| limistéar bezel (mm) | 246.65 × 94.37 (H×V) |
| cóireáil | Antiglare |
| luminance | 950 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| freagra | 35 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | SFT, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 99% sRGB |
| cúlsolas | 11S3P WLED , 10K hours , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| DJ103FA-01A | Innolux | 10.3 | 1920×720 |
