| Uimhir Pháirt | TM101JDHG33 |
| Branda | TIANMA |
| Méid | 10.1 |
| Iarratas | Industrial Medical I |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | TIANMA |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1280(RGB)×800 [WXGA] 149PPI |
| limistéar gníomhach | 216.96(H)×135.6(V) mm |
| limistéar bezel | 219.96(H)×138.6(V) mm |
| luminance | 900 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 262K/16.7M 50% NTSC |
| meáchan | 280g (Typ.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 80 °C |
| Mionsamhail | TM101JDHG33 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 229.8(H)×149(V) ×9.6(D) mm |
| cóireáil | Hard coating |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | SFT, Normally Black, Transmissive |
| foinse solais | WLED , 40K hours , With LED Driver |
| deartha le haghaidh | Industrial Medical Imaging Outdoor High Brightness |
| painéal tadhaill | Without |
| B101AW02 V0 | AUO | 10.1 | 1024×600 |
| B101AW06 V1 HW0A | AUO | 10.1 | 1024×600 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
