| Uimhir Pháirt | TM097TDHG04-62 |
| Branda | TIANMA |
| Méid | 9.7 |
| Iarratas | Pad & Tablet Industr |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | TIANMA |
| méid trasnánach | 9.7 inch |
| formáid picteilín | 1024(RGB)×768 [XGA] 132PPI |
| limistéar gníomhach | 196.608(H)×147.456(V) mm |
| limistéar bezel | 200.91(H)×152.27(V) mm |
| luminance | 350 cd/m² (Typ.) |
| treo amharc | 12 o'clock |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| dath tacaíochta | 262K 50% NTSC |
| meáchan | 200g (Typ.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (1 ch, 6-bit) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Mionsamhail | TM097TDHG04-62 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 210.2(H)×166.3(V) ×6.5(D) mm |
| cóireáil | Clear |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| am freagartha | 20/25 (Typ./Max.)(Tr+Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED [6S6P] , 30K hours , W/O Driver |
| deartha le haghaidh | Pad & Tablet Industrial |
| painéal tadhaill | Without |
