| Uimhir Pháirt | TM097TDHG04-02 |
| Branda | TIANMA |
| Méid | 9.7 |
| Iarratas | Pad & Tablet Industr |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | 6S6P |
| Comhéadan | LVDS |
| branda painéil | TIANMA |
| méid an phainéil | 9.7" |
| taifeach | 1024(RGB)×768, XGA, 132PPI |
| limistéar taispeána | 196.608(W)×147.456(H) mm |
| méid imlíne | 210.2(W)×166.3(H) ×5.85(D) mm |
| gile | 350 cd/m² (Typ.) |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| radharc is fearr ar | 12 o'clock |
| dathanna a thaispeáint | 262K 50% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 200g (Typ.) |
| comhéadan comhartha | LVDS (1 ch, 6-bit) , 30 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | TM097TDHG04-02 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 200.91(W)×152.27(H) mm |
| dromchla | Clear |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 20/25 (Typ./Max.)(Tr+Td) |
| cineál lampa | 6S6P WLED , 30K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Pad & Tablet Industrial |
