| Uimhir Pháirt | TM097QDSP01 |
| Branda | TIANMA |
| Méid | 9.7 |
| Iarratas | Pad & Tablet |
| Rún | 1536×2048 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S6P |
| Comhéadan | MIPI |
| monaróir | TIANMA |
| ainm samhail | TM097QDSP01 |
| méid scáileáin | 9.7 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 1536(RGB)×2048 (QXGA) 264PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 147.456 × 196.608 (H×V) |
| imlíne (mm) | 154.016 × 207.83 × 3.75 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Hard coating |
| luminance | 460 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | SFT, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 72% NTSC |
| cúlsolas | 6S6P WLED , No Driver |
| mais | 110g (Typ.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | MIPI (2 ch, 4 data lanes) , 61 pins Connector |
| soláthar voltais | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| uas. rátálacha | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| BF097XN | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
