| Uimhir Pháirt | TM080VDSP03 |
| Branda | TIANMA |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S3P |
| Comhéadan | |
| branda painéil | TIANMA |
| méid an phainéil | 8.0" |
| taifeach | 1200(RGB)×1920, WUXGA, 283PPI |
| limistéar taispeána | 107.64(W)×172.224(H) mm |
| méid imlíne | 114.58(W)×184.09(H) ×3.95(D) mm |
| gile | 390 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 60% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | TBD |
| voltas ionchuir | 3.3V (Typ.)(VCI) |
| timpeallacht | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -15 ~ 70 °C |
| múnla painéil | TM080VDSP03 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | - |
| dromchla | Hard coating |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | SFT, Normally Black, Transmissive |
| am freagartha | 25 (Typ.)(Tr+Td) |
| cineál lampa | 7S3P WLED |
| scáileán tadhaill | Without |
| iarratas | Pad & Tablet |
