| Uimhir Pháirt | TM080RDHP07 |
| Branda | TIANMA |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | TIANMA |
| méid trasnánach | 8.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 116PPI |
| limistéar gníomhach | 174(H)×104.4(V) mm |
| limistéar bezel | 177(H)×107.4(V) mm |
| luminance | 600 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 71% NTSC |
| meáchan | TBD |
| ráta fhráma | 60Hz |
| cineál comhéadan | Parallel RGB (1 ch, 8-bit) , 60 pins FPC |
| soláthar leictreachas | 3.3/6.0/-6.0/17/-8V (Typ.)(VCC/VDDP/VDDN/VGH/VGL) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| Mionsamhail | TM080RDHP07 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 190.4(H)×120.7(V) ×16.1(D) mm |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| am freagartha | 50 (Max.)(Tr+Td) |
| modh oibriúcháin | SFT, Normally Black, Transmissive |
| foinse solais | WLED [8S2P] , 20K hours , W/O Driver |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | Without |
