| Uimhir Pháirt | TM070RDZ50 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 400:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | TIANMA |
| méid trasnánach | 7.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 133PPI |
| limistéar gníomhach | 157.2(H)×82.32(V) mm |
| luminance | - |
| treo amharc | - |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| dath tacaíochta | 262K |
| meáchan | - |
| ráta fhráma | 60Hz |
| Mionsamhail | TM070RDZ50 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | - |
| cóimheas codarsnachta | 400:1 (Typ.) (TM) |
| am freagartha | 20 (Typ.)(Tr+Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | PCAP |
