| Uimhir Pháirt | TM070RDSG12 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 7S3P |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM070RDSG12 |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| imlíne (mm) | 167 × 106.3 × 9.8 (H×V×D) |
| limistéar bezel (mm) | 154.4 × 93.44 (H×V) |
| cóireáil | Antiglare |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 20 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | SFT, Normally Black, Transmissive |
| doimhneacht dath | 262K/16.7M 70% NTSC |
| cúlsolas | 7S3P WLED , 50K hours , With LED Driver |
| mais | 175g (Typ.) |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
