| Uimhir Pháirt | TM070RDSG08 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 10S3P |
| Comhéadan | LVDS |
| monaróir | TIANMA |
| méid scáileáin | 7.0 inch |
| uimhir picteilín | 800(RGB)×480 (WVGA) 133PPI |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| limistéar bezel (mm) | 155.4 × 94.44 (H×V) |
| luminance | 500 cd/m² (Typ.) |
| uillinn féachana | 70/70/70/60 (Typ.)(CR≥10) |
| radharc maith ag | - |
| doimhneacht dath | 262K/16.7M 70% NTSC |
| mais | 176g (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ainm samhail | TM070RDSG08 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 166.4 × 107.2 × 8.5 (H×V×D) |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | 10S3P WLED , 50K hours , With LED Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | Without |
