| Uimhir Pháirt | TM070RDHP10-00 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | Parallel |
| branda | TIANMA |
| Mionsamhail | TM070RDHP10-00 |
| méid trasnánach | 7.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 800(RGB)×480 [WVGA] 133PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 152.4(H)×91.44(V) mm |
| imlíne dim. | 165.1(H)×108.44(V) ×13(D) mm |
| limistéar bezel | 155.4(H)×94.44(V) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 35 (Max.)(Tr+Td) |
| uillinn féachana | 88/88/88/88 (Typ.)(CR≥10) |
| modh oibriúcháin | SFT, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 71% NTSC |
| foinse solais | WLED [8S2P] , 10K hours , W/O Driver |
| meáchan | 180g (Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | Parallel RGB (1 ch, 6/8-bit) , 40 pins FPC |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -45 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| BA070WS1-100 | BOE | 7.0 | 1024×600 |
| CLAA070MA0ACW | CPT | 7.0 | 800×600 |
| CLAA070ND36CW | CPT | 7.0 | 1024×600 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
