| Uimhir Pháirt | TM070RDHG34 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S8P |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM070RDHG34 |
| méid scáileáin | 7.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 134PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 154.08 × 85.92 (H×V) |
| imlíne (mm) | 164.9 × 100 × 6 (H×V×D) |
| limistéar bezel (mm) | 157.08 × 89.39 (H×V) |
| cóireáil | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | 6 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 16.7M 50% NTSC |
| cúlsolas | 3S8P WLED , 50K hours , No Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
