| Uimhir Pháirt | TM070RDHG25 |
| Branda | TIANMA |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 262K |
| Cúlsolas | 3S8P |
| Comhéadan | |
| branda painéil | TIANMA |
| méid an phainéil | 7.0" |
| taifeach | 800(RGB)×480, WVGA, 134PPI |
| limistéar taispeána | 154.08(W)×85.92(H) mm |
| méid imlíne | 164.9(W)×100(H) ×8.1(D) mm |
| gile | 450 cd/m² (Typ.) |
| uillinn féachana | 80/80/60/80 (Typ.)(CR≥10) |
| radharc is fearr ar | 6 o'clock |
| dathanna a thaispeáint | 262K 50% NTSC |
| minicíocht | 60Hz |
| meáchan | TBD |
| múnla painéil | TM070RDHG25 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 157.08(W)×89.39(H) mm |
| dromchla | Antiglare |
| cóimheas codarsnachta | 1000:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 15 (Typ.)(Tr+Td) |
| cineál lampa | 3S8P WLED , 20K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
