| Uimhir Pháirt | TM057KDH01-10 |
| Branda | TIANMA |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 320×240 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | 5S3P |
| Comhéadan | Parallel |
| monaróir | TIANMA |
| ainm samhail | TM057KDH01-10 |
| méid scáileáin | 5.7 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 320(RGB)×240 (QVGA) 70PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 115.2 × 86.4 (H×V) |
| imlíne (mm) | 144 × 104.6 × 12.8 (H×V×D) |
| limistéar bezel (mm) | 118.2 × 89.4 (H×V) |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/60/70 (Typ.)(CR≥10) |
| freagra | 20 (Typ.)(Tr+Td) ms |
| radharc maith ag | 12 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K 52% NTSC |
| cúlsolas | 5S3P WLED , 50K hours , No Driver |
| mais | 157g (Typ.) |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | Parallel RGB (1 ch, 6-bit) , Connector 33 pins |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
