| Uimhir Pháirt | TM050RDZG03-00 |
| Branda | TIANMA |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 750:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S6P |
| Comhéadan | Parallel |
| branda painéil | TIANMA |
| méid an phainéil | 5.0" |
| taifeach | 800(RGB)×480, WVGA, 188PPI |
| limistéar taispeána | 108(W)×64.8(H) mm |
| méid imlíne | 120.7(W)×77.8(H) ×5.9(D) mm |
| gile | 1000 cd/m² (Typ.) |
| uillinn féachana | 80/80/70/80 (Typ.)(CR≥10) |
| radharc is fearr ar | 12 o'clock |
| dathanna a thaispeáint | 16.7M 50% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | TBD |
| comhéadan comhartha | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| múnla painéil | TM050RDZG03-00 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 111.1(W)×67.9(H) mm |
| dromchla | Antiglare |
| cóimheas codarsnachta | 750:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 20/30 (Typ./Max.)(Tr+Td) |
| cineál lampa | 3S6P WLED , 50K hours |
| scáileán tadhaill | Without |
| iarratas | Industrial |
