| Uimhir Pháirt | TM050RDH03-40 |
| Branda | TIANMA |
| Méid | 5.0 |
| Iarratas | Industrial Portable |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | TIANMA |
| méid trasnánach | 5.0 inch |
| formáid picteilín | 800(RGB)×480 [WVGA] 188PPI |
| limistéar gníomhach | 108(H)×64.8(V) mm |
| limistéar bezel | 111.1(H)×67.9(V) mm |
| luminance | 250 cd/m² (Typ.) |
| treo amharc | 12 o'clock |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 50% NTSC |
| meáchan | 57.0g (Typ.) |
| ráta fhráma | 60Hz |
| Mionsamhail | TM050RDH03-40 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 120.7(H)×75.8(V) ×3.1(D) mm |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| am freagartha | 20 (Typ.)(Tr+Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | WLED [7S2P] , 20K hours , W/O Driver |
| deartha le haghaidh | Industrial Portable Navigation MID UMPC MP3 PMP |
| painéal tadhaill | Without |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| LM5Q321 | SHARP | 5.0 | 320×240 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| LQ050A5BS01 | SHARP | 5.0 | 320×234 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| P50AN3 | E Ink | 5.0 | 320×234 |
| PA050DS2T1 | E Ink | 5.0 | 320×234 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
