| Uimhir Pháirt | TM050RDH03-00 |
| Branda | TIANMA |
| Méid | 5.0 |
| Iarratas | Industrial Portable |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S2P |
| Comhéadan | Parallel |
| branda painéil | TIANMA |
| múnla painéil | TM050RDH03-00 0 Compatible |
| méid an phainéil | 5.0" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 800(RGB)×480, WVGA, 188PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 108(W)×64.8(H) mm |
| oscailt bezel | 111.1(W)×67.9(H) mm |
| méid imlíne | 120.7(W)×75.8(H) ×3.1(D) mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| mód taispeána | TN, Normally White, Transmissive |
| radharc is fearr ar | 12 o'clock |
| am freagartha | 20 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.7M 50% NTSC |
| cineál lampa | 7S2P WLED , 20K hours , Without Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | TBD |
| iarratas | Industrial Portable Navigation MID UMPC MP3 PMP |
| comhéadan comhartha | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
